Our Equipment
Precision Aeration Solutions offers a complete range of wastewater aeration equipment engineered for dependable performance, efficient oxygen transfer, and long-term durability. From floating turbine aerators to mounting systems and electrical controls, each component is designed to support reliable wastewater treatment across a variety of applications.
-
P5 1800
Floating Wastewater Aeration Unit – 5 Horsepower
The P5 1800 is a floating surface aerator designed to provide efficient oxygen transfer with low operating and maintenance costs.
Specifications
- Motor: 5 HP, three-phase, 60 Hz, industrial-duty
- Pontoons: UV-resistant polyethylene shell with ¼-inch wall thickness, filled with closed-cell foam
- Air/Drive Shaft: 1½-inch diameter 316 stainless steel, ¼-inch wall thickness, standard 3.5-foot length
- Turbine: High-density nylon reinforced with 30% fiberglass for excellent wear and corrosion resistance
- Air Capacity: 36 liters/second (76 cubic feet per minute) air injection
- Oxygen Transfer: Up to 4.7 pounds of dissolved oxygen per horsepower-hour, producing as much as 450 pounds of oxygen per unit per day
- Assembled Dimensions: 68" × 44" × 36"
- Approximate Weight: 300 pounds
-
PL 1800
Low Water Legs
Optional low-water legs help protect the rotating turbine in lagoons where water levels fluctuate.
Features
- Constructed from durable polyethylene
- Four legs insert directly into molded pontoon mounting cavities
- Secured using Schedule 80, 2-inch threaded end caps
- Prevent the turbine from contacting lagoon bottoms during low-water conditions
- Compatible with air shaft lengths up to 4 feet
- Vent openings at the top and bottom allow trapped air to escape during installation
-
FM 220 or 480V
Stainless Steel Fixed Mounting Bracket
This fixed mounting bracket provides an alternative installation option for applications where water levels remain relatively constant.
Features
- Manufactured from 304 stainless steel for corrosion resistance
- Reinforced with stainless steel support brackets
- Can be modified on-site to accommodate project-specific requirements
- Recommended for installations with minimal water level fluctuation
-
CP 220 or 440V
220 or 440 Volt Control Panel
Our standard control panel is designed for dependable operation while protecting the aeration system from electrical faults.
Standard Features
- Contactor or Manual Motor Starter
- Hand-Off-Auto (HOA) switch
- Short-circuit protection
- Overload protection
- Through-the-door operator
- NEMA 4X-rated polycarbonate enclosure for indoor or outdoor installation
- Rust-proof, impact-resistant construction
- Resistant to hydrogen sulfide (H₂S)
- No painting or refinishing required
-
VP 220/440
Variable Frequency Drive (VFD) Control Panel
The Variable Frequency Drive (VFD) control panel provides advanced motor protection and operational flexibility.
Features
- Over-current protection
- Phase-loss protection
- Voltage imbalance protection
- Motor stall protection
- Short-circuit protection
- Ground fault protection
- Factory-programmed operating parameters
- Soft-start capability for reduced startup stress
- Adjustable motor speed to match application requirements
- Transparent front cover for convenient monitoring without opening the enclosure
-
WS 220/440
Pre-Wired Electrical Cable
Precision Aeration Solutions supplies properly sized electrical cable based on each installation.
Features
- Factory pre-wired to the motor
- Strain-relief connectors included
- Suitable for underwater installation
- Oil-resistant construction
- Sized according to project requirements
-
GW Mount
Shore-Mounted Guy Wire System
The shore-mounted guy wire system secures floating aerators in lagoons and wastewater pits.
Features
- Recommended ¼-inch stainless steel cable
- Includes clamps, thimbles, and required rigging hardware
- Comprehensive installation instructions provided
- Technical support available for installation and anchoring questions
-
LX Mount
Aerator Layout Design
To assist with installation planning, Precision Aeration Solutions provides complimentary layout recommendations for aerator placement.
After receiving the dimensions and shape of your lagoon or wastewater pit, our team prepares a scaled layout showing:
- Recommended aerator locations
- Suggested guy wire lengths
- Electrical cable routing guidance
- Recommended wire gauge
This planning service helps simplify installation and optimize aeration coverage for your application at no additional cost.
